Vimar Idea 16145 Grey 2 Way Rocker Switch 2P 250 V 6 Terminals – ON – OFF – ON

$18.99

Vimar

SKU: 854705

In stock (7 available)

Buy Now

Free Shipping Lower 48
30-Day Returns
Not Applicable (Warranty information not included in product description)

Description
Additional information

Manufacturer: Vimar

Model Number: 2P 10AX 2-way switch grey

Series: Idea

MPN: 16145

Listed Item Condition: New/New Other

Product Details:

This item is a 2 Way 250V Grey Directional 6 Terminal Switch with Directional Arrows and Center Off (ON-OFF-ON). Box may show signs of wear from shelf life, item is new old stock.

Product Information:
Class group - Domestic switching devices
Class - Push button
Assembly arrangement - Modular device for domestic switching devices
Model - Other
Operating method - Rocker
Number of rockers - 1
Number of modules (module system) - 100
Number of poles - 2
Nominal voltage - 250 V
Rated current - 10,00 A
With lighting - No
Monitoring contact - No
Mounting method - Built-in
Type of fastening - Engage (snap)
Material - Plastic
Material quality - Thermoplastic
Halogen free - Yes
Surface protection - Untreated
Surface finishing - Matt
Colour - Grey
RAL-number (similar) - 7015
Transparent - No
Label space/information surface - Yes
Suitable for degree of protection (IP) - IP40
Device width - 24,80 mm
Device height - 50,10 mm
Device depth - 43,60 mm

Manufacture Product Notes:
2P 10AX 2-way switch grey
2P 10 AX 250 V~ 2-way switch (6 terminals) with directional arrows and central OFF position, grey. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

What's Included:

Vimar Idea 16145 Grey 2 Way Switch 2P 10AX 6 Terminals with Arrow and Center Off

Compatible Parts:

16145

Return Info: 30-Day Returns

Warranty Info: Not Applicable (Warranty information not included in product description)

Dimensions: 3 × 3 × 2 in, Weight: 0.2 lbs

Shipping Info: Free shipping applies to items being delivered within the contiguous United States (lower 48). HI, AK, PR, and all other US Territories, and International locations will have shipping calculated during checkout. Please be advised if the item is large or is a multi-piece shipment, shipping quotes may be inaccurate due to restrictions outside of our control, in those instances you will be contacted promptly.
