Summary

Vimar 13745.Q Idea Series IP55 protective electrical cover in gray, designed for four Idea modules or four Vimar 8000 special modules. Features a hinged protective lid and insulating plastic construction for compatible electrical installations requiring additional protection against dust and moisture.

• This listing includes the Vimar 13745.Q protective cover only in original clear plastic packaging. No original box, instructions, manuals, wiring, or additional accessories are included. Please review all photos for the exact item, condition, and components included.
• This is a multiple quantity listing and the unit that you will receive may be different than the unit shown, but is in the same cosmetic condition. Please review all photos for the exact item, condition, and components included.

Product Description

The Vimar 13745.Q is a four-module protective electrical cover designed for Vimar Idea Series devices and compatible Vimar 8000 special modules. Its hinged lid provides access to installed switches, outlets, and electrical controls while protecting the installation when closed.

The cover is manufactured from fully insulating plastic and features a gray RAL 7035 finish. It is designed for use with compatible four-module flush-mounted electrical boxes on smooth, waterproof wall surfaces without grooves.

When correctly installed with the lid closed, the assembly provides IP55 protection against dust ingress and water jets. With the lid open, the manufacturer specifies IPX2 protection against vertically dripping water when tilted up to 15 degrees.

The cover can be used in compatible residential, commercial, and marine electrical installations where additional environmental protection is required. The IP55 rating does not establish separate marine-grade certification.

Product Information

- Manufacturer - Vimar
- Model Number - 13745.Q
- Series - Idea / 8000
- MPN - 13745.Q
- Product Type - Protective Electrical Cover
- Color - Gray
- Manufacturer Color - RAL 7035 Gray
- Module Capacity - 4 Modules
- Compatible Modules - Vimar Idea / Vimar 8000 Special Modules
- Standard 8000 Module Compatibility - Requires Vimar 08491 Adaptors
- Cover Type - Hinged Protective Lid
- Material - Plastic
- Electrical Insulation - Fully Insulating Material
- Mounting Type - Flush-Mount Installation
- Protection Rating with Cover Closed - IP55 When Properly Installed
- Protection Rating with Cover Open - IPX2
- Installation Surface - Smooth Waterproof Wall Without Grooves
- Approximate Listed Dimensions - 140 x 90.5 x 25.5 mm
- EAN - 8007352006676
- Certifications - CE / IMQ
- Quantity - 1 Protective Cover
