Weidmuller 1478140000 PRO MAX 480W 24V 20A DIN Rail Power Supply – NOS

$238.99

This item is new and has never been used. It may be unused in its original packaging, be old stock, new open-box, new out of box, or never installed. Packaging might be missing, opened, or show minor damage. The item is fully functional and includes all accessories shown in the listing and images, unless otherwise noted.
SKU: 861963
In stock (1 available)
Buy Now
  • Free Shipping Lower 48

    Free Shipping Lower 48

  • 30-Day Returns

    30-Day Returns

  • 90-Day Warranty

    90-Day Warranty

Manufacturer:

Model Number: PRO MAX 480W 24V 20A

Series: PROmax

MPN: 1478140000

Listed Item Condition: New/New Other

Product Details:

Summary

  • Weidmüller 1478140000 PRO MAX 480W 24V 20A industrial switching power supply, designed for DIN rail installation in automation and industrial control systems. Provides a regulated 24V DC output with a nominal current rating of 20A and 480W output power.
  • This item is New Out of Box (NOS).
  • This listing includes the Weidmüller PRO MAX 480W 24V 20A power supply only. No original box, instructions, manuals, wiring, or additional accessories are included. Please review all photos for the exact item, condition, and components included.
  • Please review all photos for the exact item, condition, and components included.
  • This item was sourced from a new, uncommissioned equipment cabinet that was dismantled prior to being placed into service.

Product Description

  • The Weidmüller PRO MAX 480W 24V 20A is an industrial-grade switched-mode power supply engineered to provide reliable DC power for automation equipment, industrial machinery, and control applications.
  • The PROmax series features high efficiency, adjustable output voltage, integrated protection functions, and DC status monitoring. Its metal housing and TS35 DIN rail mounting design make it suitable for industrial electrical cabinets and control panels.

Product Information

- Manufacturer - Weidmüller
- Model Number - PRO MAX 480W 24V 20A
- Series - PROmax
- MPN - 1478140000
- Product Type - Industrial Switching Power Supply
- Rated Output Power - 480W
- Rated Output Voltage - 24V DC ±1%
- Rated Output Current - 20A
- Adjustable Output Voltage - 22.5–29.5V DC
- Rated Input Voltage - 100–240V AC
- AC Input Voltage Range - 85–277V AC
- DC Input Voltage Range - 80–370V DC
- Input Frequency Range - 45–65Hz
- Efficiency - 92%
- Operating Temperature - -25°C to +70°C (derating above +60°C)
- Mounting Type - TS35 DIN Rail
- Connection Type - Screw Terminals
- Protection Rating - IP20
- Housing Material - Corrosion-Resistant Metal
- Status Indication - LED and Relay Contact
- Short-Circuit Protection - Yes
- Parallel Connection - Up to 3 Units
- Dimensions (W x H x D) - 90 x 130 x 150 mm
- Net Weight - 2,000 g
- EAN - 4050118286137
- Country of Origin - China

What's Included:

  • Weidmuller 1478140000 PRO MAX 480W 24V 20A DIN Rail Power Supply

Compatible Parts:

Return Info: 30-Day Returns

Warranty Info: 90-Day Warranty

Dimensions: 6 × 4 × 6 in, Weight: 4.25 lbs

Shipping Info: Free shipping applies to items being delivered within the contiguous United States (lower 48). HI, AK, PR, and all other US Territories, and International locations will have shipping calculated during checkout. Please be advised if the item is large or is a multi-piece shipment, shipping quotes may be inaccurate due to restrictions outside of our control, in those instances you will be contacted promptly.
