We recently acquired a lot of parts from a marine distributor reducing excess inventory.
Dealer demo stock.
The Oceanic Systems’ 4410 16 Channel Switch Input Module monitors switch closure devices and
reports their status over the NMEA2000® network.
These devices can include fire/smoke/carbon monoxide detectors, bilge and flood float
detectors, doorway and porthole closure detectors, valve status detectors and many more.
With this module and suitable NMEA2000® displays the status of all these items can be viewed
anywhere on the vessel.
The unit has PLC quality inputs that are manufactured to IEC 61131 and IEC61000 standards so
they are optically isolated and fully protected against ESD, Voltage Surges and Transients to
ensure the most reliable operation at all times.
It is compatible with either 12 or 24 Volt systems and requires NO user setup menus but the
simple setting of two small rotary address switches so multiple Switch Input Modules can exist
on the same network.
The connections to the unit are made via boat builder preferred WAGO Cage Clamp terminal
blocks which allow either solid or multistranded wires from 0.08 to 1.5mm² to be connected
quickly and securely. Each switch input also has a tell tale green LED to indicate when it is
active.
The 4410 can be either panel mounted or din rail mounted using the mounting clips provided.
This unit is designed to operate in a protected marine environment such as an engine room. It is
very important that it is installed and set up correctly according to this manual. Please read and
follow the installation and setup instructions carefully to achieve the best results.
Free shipping to the contiguous US
