This system is as good as they come! This is a 30KW S-Band radar.
Unlike the X-band radars, this radar is able to see through rain and other various weather conditions.
This radar also has long range bird detection.
This is the “AC” version, meant for 100-115 VAC systems, scanner motor runs on 3 phase 220v. We have marine monitors listed separately if needed, otherwise, use the system with your existing VGA display.
Included in this listing:
RPU-011 Radar Processor – Great condition. This unit requires 100-115 VAC
30KW RSB-0026-066 Pedestal – Pedestal is in good condition, (3 Phase 220 VAC for motor). Does not have the de-icer. Missing one of the cable glands.
SN30AF/ANT10 – 10 foot antenna with some minor scratches, was painted white by the previous owner.
PSU-004 – Power supply, missing the cable clamp (pictured).
Interconnect cable – 54 feet
RCU-011 Keypad – Great condition with 40 feet of cable attached
PLEASE NOTE: Additional wires will have to be ran in order to properly hook up this system. The motor itself runs on 3 phase 220 VAC. You will need at least a 3 conductor wire from PSU-004 to radar pedestal (Motor circuit). The PSU-004 also requires a 3 conductor wire from the PSU-004 to a 3 phase 220 VAC from Ship Mains (Breaker). The PSU-004 also requires a 3 conductor from the RPU-011 Processor to the PSU-004 to provide the PSU-004 with 12 VDC.
Requires heading and speed from other on-board electronics.
This is the system you’ll see on the highest of high end motoryachts, sportfishing boats, and of course, commercial vessels.
